Important attributes
| Operating Weight | 1.8 Ton | Bucket Capacity | 0.04 m³ |
|---|---|---|---|
| Engine Brand | Famous Brand | Power (kW) | 11.8 kW |
| Working Hours | 0–2000 Hours | Machine Weight | 1795 KG |
| Hydraulic Cylinder Brand | Famous Brand | Hydraulic Pump Brand | Famous Brand |
| Hydraulic Valve Brand | Famous Brand | Core Components | Pressure Vessel, Motor, Bearing, Pump, Gear, Gearbox, Engine, PLC |
| Year of Manufacture | 2021 | Place of Origin | Jiangsu, China |
| Machinery Test Report | Available | Video Outgoing-Inspection | Available |
| Description | Unit | XE17U |
|---|---|---|
| Operating Weight | Kg | 1795 |
| Bucket Capacity | m³ | 0.04 |
| Description | Unit | Value |
|---|---|---|
| Travel Speed (H/L) | km/h | 3.1 / 2.1 |
| Gradeability | ° | 30° |
| Ground Pressure | kPa | 28.5 |
| Bucket Digging Force | kN | 16 |
| Arm Digging Force | kN | 10 |
| Maximum Traction Force | kN | 15.6 |
| Description | Unit | Value |
|---|---|---|
| Max. Digging Height | mm | 3475 |
| Max. Dumping Height | mm | 2415 |
| Max. Digging Depth | mm | 2290 |
| Max. Vertical Digging Depth | mm | 1750 |
| Max. Digging Radius | mm | 3900 |
| Min. Swing Radius | mm | 1550 |
